PVC LSZH Material Fiber Optic Patch Cord , SC Multimode Fiber Cable

Name: PVC LSZH Material Fiber Optic Patch Cord SC Multimode Fiber Cable
Brand: SINOHONE
Price: 1 USD

Quality PVC LSZH Material Fiber Optic Patch Cord , SC Multimode Fiber Cable for sale

Brand Name : SINOHONE

Model Number : SC

Certification : CPR FCC CE RoHS ISO9001

Place of Origin : Sichuan, China

MOQ : 2000 meters

Price : USD $0.38~$0.58 / meter

Payment Terms : L/C, D/P, T/T, D/A, Western Union, MoneyGram

Supply Ability : 50000 pieces per month

Delivery Time : 5-8 work days

Packaging Details : Standard packing in sealed box or according to customers' requirements

Product Name : SC Fiber Optic Patch Cord

Connector Type : SC

Fiber Type : G657,G652

Cable Diameter : 3.0mm

Cable Material : PVC or LSZH

Diameter : 0.9, 2.0, 3.0mm

Repeatability : ≤0.2dB

Contact Now

PVC LSZH Material SC Fiber Optic Patch Cord Single Mode Multimode Cable

Short Description:

The SC Fiber Optic patch cord is made by 2.0mm or 3.0mm PVC sheath simplex or duplex indoor cable and then is completed with SC. ST. FC or LC connectors.

It provides a stable and reliable connection both SM or MM and single or dual fiber. PC, UPC and APC is optional.

Features

Low insertion loss. High return loss.
High stability and reliability.
Low insertion loss and high return loss
Excellent end face geometry parameter
Special specification available upon cutomer's requirements

Applications

Data transmission Networks Image transmission Networks
CATV Optical test instrument Photoelectric automatic control system

Product Sketch Map

PVC LSZH Material Fiber Optic Patch Cord , SC Multimode Fiber Cable

Figure 1: SC/APC-SC/UPC-SM-SX
Remarks:1.L”stands for the order length;

Main Material Specification

Project	Specifications	Remarks
Fiber Type	G657,G652	Accord with ROHS and IEC Standard
Cable Diameter	3.0mm
Cable Material	PVC or LSZH
Cable Color	Yellow
Connector Type	SC/APC&SC/UPC
Insert	2.499±0.002mm
Concentricity	less than 0.5um

Optical Performance

Item	Unit	Index	Remarks
Out of roundness	/	less than10%
Bend radius	mm	≥30
Attenuation value	dB/km	less than 0.36(1

PVC LSZH Material Fiber Optic Patch Cord , SC Multimode Fiber Cable

Product Tags:

fiber optic cable adapter

simplex fiber optic cable
